Abstract Privacy Screen 30 — Fiber Laser DXF for Pergola Side Panel
Sculpted abstract pattern with continuous closed geometry — perfect for fiber laser on stainless or aluminium, and equally clean on plasma at higher thickness.
Formats
DXF, SVG
Size
scalable
Materials
stainless steel, mild steel, aluminum, brass, wood, acrylic, MDF
Difficulty
intermediate
- ✓ Instant download after payment
- ✓ Personal + commercial license included
- ✓ Tested for clean cuts
- → Full license details
Buying multiple designs? Get our Full Access Bundle for one flat $49.99.
See bundle details →What’s included
.dxf— universal cutting format optimised for fiber laser, CO2 fiber laser, plasma and CNC routers (LightBurn, RDWorks, Fusion 360, Mach3, EZCAD).svg— vector format (Illustrator, Inkscape, Glowforge, xTool)
Fiber laser ready
This design is built around the kind of clean, continuous geometry a fiber laser loves: every line closes, every loop bridges, and the cut path is single-pass. Drop the .dxf straight into your fiber controller and run — no preprocessing, no manual cleanup.
Tested-clean on: stainless steel, mild steel, aluminium, brass, copper. Typical settings for 1.5 mm steel — 500 – 1000 W, ~60 mm/s feed, single pass, ~0.1 mm kerf. No scaling needed for most projects.
Cutting notes by machine
Fiber laser (recommended for metal) Set kerf to ~0.1 mm. Use O₂ for ≥ 3 mm mild steel, N₂ for stainless or premium finish. Lead-in/lead-out are baked in.
Plasma cutter Set kerf to ~1.0 – 1.5 mm. Works beautifully at 3 – 12 mm mild steel. Powder coat for outdoor use.
CNC router Use a ≤ 3 mm carbide bit for the finer features. Best on plywood, MDF, acrylic.
License
Personal + small-scale commercial use included. See the full license for limits on resale of the files themselves.
